Fiber Optic Solutions for Telecommunications Providers

The honest answer is an architecture, not a headline number: each standardized 7HP splice module carries up to 24 fibers, and the modular subracks accept these modules in any combination — density grows with your subscriber take-up. For fixed link structures, SlimConnect concentrates connections on one height unit.

Within defined limits. The 7HP splice and front modules are shared between the VarioConnect subracks and the 1U modular system — a module bought today can be reused when a site grows. SlimConnect is factory-configured with fixed adapters and has no exchangeable modules; RailConnect follows the same 7HP architecture as a self-contained DIN rail unit.

LC, SC and E-2000 in the common APC and UPC variants, for singlemode and multimode fiber. Front modules and adapters are combined per project; in the modular systems a later connector change is a module swap, not a frame replacement. For critical links, DIAMOND E-2000 offers typically ≤ 0.1 dB insertion loss.

Designed around FTTH rollout reality: pre-assembled couplings and pre-installed pigtails reduce on-site preparation, front access means no rack has to be pulled apart for service, and modules come out tool-free without disturbing neighbouring links.

F4P is our own system brand: made in Europe, with German Engineering behind the design and short supply routes to your project. For connectivity we are an official partner of DIAMOND SA (Switzerland) — Swiss precision ferrule technology that sets the reference for connector quality.

The portfolio follows the levels of an FTTH network: central PoP stations and backbone nodes — VarioConnect 3U; primary and secondary distribution points — VarioConnect 3U or the 1U modular system; space-critical district and building distributors — SlimConnect 1U; control cabinets — RailConnect 7HP on TH35 rail.

The range is built as a price ladder: factory-configured SlimConnect boxes keep cost per port down where the link structure is fixed, while modular VarioConnect systems protect the investment where requirements change. Project pricing and volume discounts on request — send your quantities via the contact form.

Personal project consulting by our team: we review your network structure, recommend the modular/fixed split per site type, and prepare an orderable parts list. The online tools do the groundwork with loss budget checks and 3D configuration with real article numbers.

Yes — that is the core idea of the architecture. The 19″ systems are designed for existing racks, so brownfield sites are upgraded without replacing the cabinet. In the modular systems — the 1U modular system and VarioConnect — additional 7HP modules are fitted in service: existing splices and live links stay untouched while capacity grows, and when a technology step changes the connector concept, individual modules are exchanged instead of the whole frame. SlimConnect boxes are factory-configured, so growth there is planned per construction phase rather than per module. For control cabinets, RailConnect retrofits onto the existing TH35 DIN rail — no 19″ rack required.

Delivery time depends on the project — you receive a binding date with your quote. European manufacturing keeps supply routes short and planning reliable.
