19-inch subracks
Modular 19-inch subracks. The 1U system holds 3 × 7HP, the 3U system 12 × 7HP.
Choosing the subrack: three points that have to last ten years
The subrack is the longest-lived decision at the distribution level — the modules inside it change, the grid does not.
The frame first, then the fibres
Choose the right subrack and you expand later without rebuilding. Choose one too small and you replace the whole thing.
Populate as needed
One subrack, fitted with a single module on day one, filled up over the years — without disturbing the existing infrastructure.
One grid for everything
7HP is the common interface: splice module, front module and blanking plate sit in the same slot.
What defines this line
Characteristics shared by every version.
1U subrack for holding front modules
The modular 1U subracks are supplied empty in their basic configuration — without screw fittings, splice trays, front modules, etc.
3U subrack for holding splice modules
Characteristics of the 19-inch subracks line
Every version in this line with its order number. Prices on request and in the shop for registered customers.
Characteristics of the 19-inch subracks line
| Max. splice cassettes | 4 pcs. (96 pcs. splice protectors) |
|---|---|
| Max. splice modules | 12 St. (Max. 144 Fasern) |
| Max. front modules | 3 St. 7TE |
| Max. cable glands | 6 St. M25 |
| Max. cables | 24 St. M20 |
| Height | 1HE, 3HE |
| Width | 19” |
| Body material | Stahl 1,25mm |
| Colour | RAL7035 / Grau, RAL9005 / Schwarz |
The subrack is the investment, not the module
A subrack stays in place for ten years and longer. The modules inside it change, grow and get replaced — which is why the choice of grid decides how far the whole distribution level can be expanded.
Versions and order numbers
4 items — show all
| Order number | Designation | Size (W×H×D) |
|---|---|---|
| 110001 | Modulares 1HE System BGT 1HE 3X7TE BL | 490 × 45 × 260 mm |
| 110006 | Modulares 3HE System BGT 3HE 19" 12X7TE BL | 489 × 135 × 365 mm |
| 120001 | Modulares 1HE System BGT 1HE 3X7TE GR | 490 × 45 × 260 mm |
| 120009 | Modulares 3HE System BGT 3HE 19" 12X7TE GR | 489 × 135 × 365 mm |
Four reasons to plan the subrack with us
Made in Europe
The F4P systems are manufactured in Europe — short paths from design to production, even for custom populations.
1U for 3 × 7HP, 3U for 12 × 7HP
The subrack sets the grid, the modules fill it — populate as needed and expand over the years.
Data sheet and part number for every version
Every available version is documented. The enquiry goes out with the part number, not with a description.
One connector system across the entire line
The same E-2000® connection level in every form factor: consistent handling, one spare-parts profile, no system breaks in the installed base.
Calculate and configure first, then enquire
Three tools with real part numbers — check the optical budget and put your configuration together live in 3D.
Attenuation budget calculator
Add up connectors, splices and fibre lengths and check the total attenuation against the budget — before the OTDR acceptance test measures it.
Subrack configurator
Populate a 19″ subrack slot by slot with splice and front modules — including the bill of materials for your quotation.
Splice box configurator (3D)
Configure form factor, port count, fibre type and polish live — with a real part number for your enquiry.
Datasheet for download
19-inch subracks
Dimensions, versions, order numbers and connection technology.
