Cable management
Patch trays, patch panels, cable combs, blanking plates and cable entry modules.
Cable management in the rack: three points that count in operation
Anything left unguided costs time at the next intervention — and adds attenuation when bend radii are undercut.
Cables find their own way
Without guided routes, every patch cable takes the shortest path — straight across the front. At the next intervention, that costs time.
Holding bend radii
Guided patching keeps to the minimum bend radii. Anything that lies pinched attenuates — and only shows up in operation.
Close off empty slots
Blanking plates maintain airflow and dust protection for as long as a slot stays empty.
Characteristics of the Cable management line
Every version in this line with its order number. Prices on request and in the shop for registered customers.
Characteristics of the Cable management line
| Height | 1,5HE, 1HE, 20 mm, 2HE, 3HE |
|---|---|
| Width | 120 mm, 19”, 7TE, 80 mm |
| Material | Stahl, Stahl / Kunststoff |
| Material thickness | 1,5 mm, 2 mm, 3 mm |
| Colour | RAL7035 / Grau, RAL9005 / Schwarz |
Patching is not an accessory
Cable management decides how long a distribution level stays easy to maintain. It belongs in the same planning as the splice level — and in the same 19-inch grid.
Versions and order numbers
16 items — show all
| Order number | Designation | Weight |
|---|---|---|
| 301000 | Kabelkamm KK 2HE GR | 0,17 kg |
| 301001 | Kabelbügel KB RI 120 GR | 0,12 kg |
| 301002 | Kabelkamm KK 2HE BL | 0,17 kg |
| 301003 | Kabelbügel KB RI 120 BL | 0,12 kg |
| 311000 | Rangierwanne RW 1,5HE GR | 0,95 kg |
| 311001 | Rangierpanel mit Deckel RP 1,5 HE GR | 1,05 kg |
| 311002 | Rangierpanel RP 1HE LWL GR | 1,05 kg |
| 311003 | Rangierwanne RW 1,5HE BL | 0,95 kg |
| 311004 | Rangierpanel mit Deckel RP 1,5 HE BL | 1,05 kg |
| 311005 | Rangierpanel RP 1HE Universal GR | 1,05 kg |
| 311007 | Rangierpanel RP 1HE LWL BL | 1,05 kg |
| 311106 | Rangierpanel RP 1HE Universal BL | 1,05 kg |
| 841088 | Blindplatte BP 3HE7TE BL | 0,11 kg |
| 841089 | Kabeleinführungsmodul KEM 3HE7TE M20 BL | 0,11 kg |
| 841090 | Blindplatte BP 3HE7TE GR | 0,11 kg |
| 841091 | Kabeleinführungsmodul KEM 3HE7TE M20 GR | 0,11 kg |
Four reasons to plan the patching level with us
Made in Europe
The F4P systems are manufactured in Europe — short paths from design to production, even for custom populations.
Order as part of the system
Cable management panels, cable entries and blanking plates sit in the same 19″ grid as the distribution levels.
Data sheet and part number for every version
Every available version is documented. The enquiry goes out with the part number, not with a description.
One connector system across the entire line
The same E-2000® connection level in every form factor: consistent handling, one spare-parts profile, no system breaks in the installed base.
Calculate and configure first, then enquire
Three tools with real part numbers — check the optical budget and put your configuration together live in 3D.
Attenuation budget calculator
Add up connectors, splices and fibre lengths and check the total attenuation against the budget — before the OTDR acceptance test measures it.
Subrack configurator
Populate a 19″ subrack slot by slot with splice and front modules — including the bill of materials for your quotation.
Splice box configurator (3D)
Configure form factor, port count, fibre type and polish live — with a real part number for your enquiry.
