DIAMOND accessories
Blanking plates, patch cable guides and accessories for the DIAMOND range.
Accessories: three points that make a delivery complete
A missing blanking plug does not hold up a building site — a missing adapter does.
Reordering without queries
Anyone who knows the adapter’s part number orders an exact match for the installed base — even years later.
Small parts keep schedules
Blanking plugs, protective caps and panels are cheap — and block acceptance if they are missing.
One connector system, one spare-parts profile
Anyone running the same connector system across the lines holds one stock instead of three.
Characteristics of the DIAMOND accessories line
Every version in this line with its order number. Prices on request and in the shop for registered customers.
Characteristics of the DIAMOND accessories line
| Height | 3HE |
|---|---|
| Width | 7TE |
Accessories from the same production as the enclosure
Adapters and small parts come from DIAMOND SA itself — the same tolerances, the same testing. That is the difference between a spare part that fits and one that only looks as if it does.
Versions and order numbers
8 items — show all
| Order number | Designation |
|---|---|
| 159000 | DIAMOND Blindplatte 3HE/7TE G300-BLD-00FV000 |
| 159001 | DIAMOND Zugentlastungsset Blindplatte G120-01C-00FT024 |
| 159002 | DIAMOND Zugentlastungsset M20 0° G120-01C-00FT022 |
| 159003 | DIAMOND Zugentlastungsset M20 30° G120-01C-00FT023 |
| 159004 | DIAMOND Nagetierschutz 0° G120-02C-00FT008 |
| 159005 | DIAMOND Zugentlastungsset M25 0° G120-01C-00FT025 |
| 319001 | DIAMOND Patchkabelführung mit Haken – G120-02C-00FT052 |
| 319002 | DIAMOND Patchkabelführung mit Haken – G120-00C-00FT052 |
Four reasons to source the accessories from us
Authorised distribution partner of DIAMOND SA
Swiss precision from a single source — E-2000® with typ. ≤ 0.1 dB insertion loss and a spring-loaded laser protection shutter.
Accessories that belong to the line, not picked out of a general range
Adapters, panels and small parts are assigned to the enclosures — the enquiry goes out with the part number, not with a description.
Data sheet and part number for every version
Every available version is documented. The enquiry goes out with the part number, not with a description.
One connector system across the entire line
The same E-2000® connection level in every form factor: consistent handling, one spare-parts profile, no system breaks in the installed base.
Calculate and configure first, then enquire
Three tools with real part numbers — check the optical budget and put your configuration together live in 3D.
Attenuation budget calculator
Add up connectors, splices and fibre lengths and check the total attenuation against the budget — before the OTDR acceptance test measures it.
DIAMOND configurator (3D)
Configure Future and Fusion Box with E-2000 live — with a real part number for each configuration, ready for your enquiry.
Subrack configurator
Populate a 19″ subrack slot by slot with splice and front modules — including the bill of materials for your quotation.
Datasheet for download
DIAMOND accessories
Dimensions, versions, order numbers and connection technology.
Where this line is used
The same technology in different environments — these pages describe what each sector needs.
Wind power & offshore
Robust fiber optic solutions for renewable energies and offshore plants
Network operators
Professional fiber optic solutions for stable and scalable network infrastructures
Data centers
Space-saving high-performance solutions for maximum port density and rack efficiency
Datasheets for download
Everything on this page as a PDF — for tenders, planning and sharing within the project.
DIAMOND accessories
Dimensions, configurations, order numbers and connection technology for the DIAMOND accessories line.
DIAMOND patch panels and boxes
Dimensions, configurations, order numbers and connection technology for the DIAMOND patch panels and boxes line.
Full catalogue
The complete range at a glance — splice boxes, modules, subracks, cable management and the DIAMOND product line.
Find the right configuration
Tell us the application, fibre count and connection technology — we will propose the version that fits.
Project pricing and volume discounts on request. Lead time depends on the project — you receive the binding date with the quotation.
